DC Circuit Breaker ARC 2000

Features

Their compactness and ability to operate either vertically or horizontally make the ARC2000A circuit breakers particularly adaptable to assembly in :
* Electrical blocks or cases for rolling stock (for horizontal mounting, it is recommended to use horizontal fitting option)
* Shielded cases of the industrial type cabinets for fixed installations.

Applications

The ARC 820 and ARC 1520 circuit breakers are direct current unipolar devices with a bi-directional over-current and trip free
release. These are electromagnetic control devices.

Products from 2000A ARC range have a common general architecture and differ by the size of the arc chute (function of the operating voltage).

Benefits

The circuit breaker design leads to an easy maintenance and high number of operations. The main wearing parts may be changed without completely dismantling the circuit breaker.

Material Number

TRK5650516200

Attachments

[0682p00000T6H6d] Technical_Description_ARC2000_Ed1.pdf
